Diameter 12mm 3-12v micro dc worm gear motor High torque low speed N20 DC brushed with magnetic encoder
Motor Type: DC worm gear motor
Item NO. DGA12-N20-AN-EN
Voltage 3V~24V
Speed 5~500RPM
Working Current 0.3A Max
Body Diameter:12MM
Product Feature :
1.Widely used, economical and practical.
2.Light appearance and structure design.
3.The structure is relatively compact, the return gap is small, the precision is high, and the service life is long.
4.The price is a little expensive.
Quick Detail:
· Metal housing
· DC6V~12V Voltage options
· Max torque 3Nm
· 5~500rpm high speed
· Connector type customized
· Long lifetime
· CE, ROHS compliant
· 1 Year Warranty
Description:
N20 is a DC gear motor made of precious metal brushed DC motor with precision metal reducer. The outer dimensions are oblate, outer diameter 12, flat 10, motor length 15mm, the length of the gearbox is
18MM, DC motor because of mature technology, low price, simple drive control and widely used in cameras, copiers, door locks, optical drives, precision instruments, cameras and other fields.
After supporting the gearbox, the torque is greatly increased, the speed is reduced, and it is easy to control.
For the gearbox, we have different gearbox for you to choose from, regular gearbox and worm gearbox. For regular geabox, output shaft and motor shaft are on the same direction. For worm gearbox, output shaft is vertical to motor shaft.
Our gearboxes are processed and assembled by imported machine tools to ensure that the accuracy of each gear is higher than other manufacturers in the same industry, so the gearbox is stable in transmission, low in noise, high in efficiency, reliable in structure, long in life and quality.
There is a encoder attached at the bottom of the motor. It is a magnetic encoder with hall component. A hall component can test the position of a magnet ring. Therefore, when a motor rotates a turn, there will be several signal pulses generated (Pulse number depends on magnet poles on magnet ring). In this case, the motor will provide feedback signal, and users can tell how many turns the motor rotates based on encoder signal.
Specification:
| Item | Dc worm gear motor |
| Size | Diameter12mm |
| Working Voltage | 6v |
| Speed | 15RPM |
| Torque | 1.3kg.cm |
| Working Current | 85mA Max |
| Typical Current | 62mA |
| Lifetime | 200hours constant run |
| Certificate | CE,ROHS |
Typical Specification:
Note:Motor's voltage,speed,wire length,connector type can be customized
Typical application
Our products widely used in Robot, 3D pen and machine, Power Lock ,Electronic Lock ,Optic equipment ,Micro Mechanism, money detcotor, printer ,pump etc.
FAQ
Q: How to order?
A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit → mass production →
cargo ready → balance/delivery → further cooperation
Q: How about Sample order?
A: Sample is available for you. please contact us for details. Once we charge you sample fee, please feel easy, it would be refund
when you place formal order.
Q: Which shipping way is available?
A: DHL, UPS, FedEx, TNT, EMS, China Post,Sea are available.The other shipping ways are also available, please contact us if you
need ship by the other shipping way.
Q: How long is the deliver[Producing] and shipping?
A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.
Q: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents.We apologize for any inconveniences.
Q: How to confirm the payment?
A: We accept payment by T/T, PayPal, the other payment ways also could be accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
